Built With Premium Components
With a wide range of frame sizes available it is possible to have a carbon road bike that perfectly matches your measurements.
Built With Premium Components
Flat mount disc brakes and 12mm thru axles make for great braking and super reactive acceleration.
Balanced Geometry
A monocoque one piece frame construction combined with stunning aesthetics, offers the perfect price/quality ratio. i
Advanced Aerodynamics
Internal cable routed system, standard BSA bottom bracket and a 31.6 seat post allow for easy position management and the geometry ensures longer distance can be undertaken with ease.
Geometry
XS (49) | S (52) | M (54) | L (56) | XL (58) | |
---|---|---|---|---|---|
ST | 490 | 520 | 540 | 560 | 580 |
TT | 515 | 535 | 546 | 565 | 572 |
HT | 122 | 142 | 152 | 167 | 182 |
HA | 70.5 | 72 | 72 | 72.3 | 72.5 |
CA | 74 | 74 | 73.5 | 73 | 73 |
BB | 70 | 70 | 70 | 70 | 70 |
RC | 402 | 402 | 402 | 402 | 402 |
FC | 576 | 583 | 589 | 600 | 605 |
OFFSET | 43 | 43 | 43 | 43 | 43 |
WB | 967 | 975 | 985 | 992 | 997 |
STACK | 516 | 542 | 552 | 567 | 582 |
REACH | 366 | 379 | 382 | 391 | 95 |
Frequently Asked Questions
- How much does the Moda Vivo frame weigh?
- What warranty is offered on the frame?
- What type of bottom bracket does it take?
- Are the cables internally routed?
- What is the maximum tyre size?
- How many bottle cage mounts arethere?
- Is the bike fitted with bottles and cages?
- Are the axles thru-axle or quick release?
- Is it mudguard compatible?
- What is the maximum rider weight?
- Is the bike supplied with pedals?
The Toray T1000/T800 carbon frame weighs 1140±30g in size
Medium (54) and the uncut forks weigh 410±15g
Because all our Moda bikes come in a range of sizes and are
custom built with a wide variation of componentry, its difficult to give you a weight
of a complete bike.
The Moda Vivo frame is guaranteed against manufacturing defects for a period of 3 years.
Paintwork for 1 year.
The standard manufacturer's warranty covers all other
components.
The Moda Vivo has a Standard
BSA Threaded bottom bracket, allowing for ease of maintenance and enhanced reliability.
Partially. The frameset enables all the cables to be run internally through the frame behind
the head tube.. This allows the Moda Vivo to assembled with a wide range of steering components whilst also benefiting for fast easy adjustment of rider position
management.
The Moda Vivo frame will
accommodate size 28 mm tyres quite comfortably (manufacturer dependant up to size 30mm).
Two. One is situated on the down tube and one on the seat
tube.
Yes, two black composite Moda bottle cages are supplied and
fitted together with a Moda tool and Moda drinking bottle when purchasing a Moda Vivo.
The Moda Vivo frame/bike is supplied with two M12 x 1.5 front and rear thru-axles.
Due to the Moda Vivo being a performance-endurance bike,
there aren't any integrated mudguard mounts.
We recommend a maximum rider plus bike weight of up 120kgs
subject to proportion of seat post elevation. (details available on request)
Due to the many different systems people use, we don't supply pedals with bikes. However, you can choose from a selection of the best-selling
pedals when you configure your bike and again we can supply at a competitive price. (details available on request)
