Built With Premium Components
The newly developed high-end UD carbon frame with EPS technology is equipped with a pressfit 41 oversize bottom bracket.
Balanced Geometry
The 1-1/2″ head tube and manufactured to the latest technologies for clean internal DCR/ACR cable routing.
Advanced Aerodynamics
Larger 32mm tyre clearance for maximum comfort on todays demanding roads. The ALTO excels in every way and is probably the most performance focused frame in the Moda range. Coming in at circa 970g for a size medium.
Built With Premium Components
In addition to its perfect form and its incredible race attributes, this bike impresses with its minimal outline and an outstanding sense of comfort and style, security and control. The ALTO, perfected by years of know-how, built for the demanding athlete.
Geometry
| XXS (46) | XS (49) | S (52) | M (54) | L (56) | XL (58) | |
|---|---|---|---|---|---|---|
| ST | 435 | 445 | 465 | 485 | 505 | 525 |
| TT | 505 | 515 | 531 | 543 | 562 | 577 |
| HT | 95 | 105 | 115 | 135 | 155 | 175 |
| HA | 70.5 | 71 | 71.5 | 72 | 72.5 | 72.5 |
| CA | 75.5 | 75 | 74 | 74 | 73.5 | 73.5 |
| BB | 72 | 72 | 72 | 72 | 72 | 72 |
| RC | 406 | 406 | 406 | 406 | 406 | 406 |
| FC | 574 | 579 | 582 | 591 | 599 | 615 |
| OFFSET | 45 | 45 | 45 | 45 | 45 | 45 |
| WB | 968 | 974 | 977 | 984 | 985 | 1010 |
| STACK | 502 | 513 | 524 | 545 | 565 | 585 |
| REACH | 371 | 378 | 380 | 386 | 395 | 404 |
Frequently Asked Questions
- How much does the Moda Alto frame weigh?
- What warranty is offered on the frame?
- Can the Moda Carbon handlebars accommodate computer mounts?
- What type of bottom bracket does it take?
- Are the cables internally routed?
- What is the maximum tyre size?
- How many bottle cage mounts are there?
- Is the bike fitted with bottles and cages?
- Are the axles thru-axle or quick release?
- Is it mudguard compatible
- What is the maximum rider weight?
- Can I fit tri bar extensions to the Moda carbon aero Handlebars?
- Can I fit lights to the Moda carbon aero handlebars?
- Is the bike supplied with pedals?
The Toray T1000/T800 carbon frame weighs 975±30g in size Medium (54) and the uncut forks weigh 420±15g
Because all our Moda bikes come in a range of sizes and are custom built with a wide variation of componentry, its difficult to give you a weight of a complete bike.
The Moda Alto frame is guaranteed against manufacturing defects for a period of 3 years.
Paintwork is covered for 1 year
The standard manufacturer's warranty covers all other
components.
For all warranty terms and conditions click here
Yes but wed suggest a computer mount with a slender clamp. Moon, Whahoo or K-edge are all good options.
The Moda Alto has a Press fit 41 bottom bracket, allowing for
ease of maintenance and enhanced reliability.
Yes. The Moda Carbon integrated handlebars, in combination with the frameset, enable all the
cables to be fully hidden. This gives the Moda Alto’s minimal lines for a sleek
outlook and maximum drag savings.
The Moda Alto frame will accommodate size 33mm tyres quite comfortably (manufacturer dependant)
Two. One is situated on the down tube and one on the seat tube.
Yes, two black composite Moda bottle cages are supplied and
fitted together with a Moda tool and Moda drinking bottle when purchasing a Moda Alto
The frame/bike is supplied with two M12 x 1.5 front and rear thru-axles.
Due to the Alto being a performance-endurance bike, there aren't any integrated mudguard mounts.
We recommend a maximum rider plus bike weight of up 120kgs
subject to proportion of seat post elevation (details available on request)
In this instance we’d recommend using one of our Deda alloy
handlebar options if you intend fitting a tri bars. (details
available on request)
Yes but as with an manufacturers aerodynamic profile top
portion of the handlebar, this makes finding compatible lights and computers a little more difficult. To overcome this, we'd suggest combining your computer mount with a dual compatible mount which we can supply. (details available on
request)
Due to the many different systems people use, we don't supply pedals with bikes. However, you can choose from a selection of the best-selling
pedals when you configure your bike and again we can supply at a competitive price (details available on request)
